D-link Unshielded 24 port full loaded patch panel
₵670.00
Product Highlights
Pre-Loaded Convenience: Includes 24 high-quality Cat6 UTP keystone jacks, allowing for immediate installation right out of the box.\n\nStandard 1U Rackmount: Designed to fit perfectly into any standard 19-inch equipment rack, occupying only 1U of vertical space.\n\nGold-Plated Contacts: Features 50 micro-inch gold plating on the jack contacts to ensure superior signal transmission and prevent corrosion.\n\nUniversal Wiring: Includes clear, color-coded labels for both T568A and T568B wiring schemes for error-free termination.\n\nTool Compatibility: The IDC terminals are compatible with both 110 and Krone punch-down tools, supporting 22-26 AWG solid or stranded wire.\n\nIntegrated Cable Management: Comes with a rear support bar to organize and secure incoming cables, reducing strain on the termination points.\n\nClear Identification: Features transparent ID plate holders with paper inserts above each port for easy labeling and network mapping.
Why Shop With Us
Fast Delivery
Delivery within 24-48 hours in Accra, 2-5 days nationwide
Secure Payment
100% secure payment options with SSL encryption
Easy Returns
7-day return policy for damaged or wrong items
24/7 Support
Dedicated customer support available anytime
Product Specifications
Type:Patch Panels
Compatibility:Universal
The D-Link 24-Port Unshielded Fully Loaded Patch Panel (NPP-C61BLK241) is a high-density networking component designed to organize and manage ethernet cabling in a standard 19-inch rack. As a \"Fully Loaded\" unit, it comes pre-installed with 24 Cat6 RJ45 keystone jacks, eliminating the need for separate module purchases. The panel is constructed from heavy-duty SPCC steel and features a modular design where ports are grouped into six-port blocks, making it a reliable and unmanaged physical layer solution for high-speed Gigabit networks.
Technical Specifications
Brand:D-Link\n\nModel Number: NPP-C61BLK241\n\nPort Count: 24 Ports (1U height)\n\nCategory Rating: Cat6 (Backwards compatible with Cat5e/Cat5)\n\nShielding Type: UTP (Unshielded Twisted Pair)\n\nPanel Material: 1.5mm thick SPCC steel (Black powder-coated)\n\nJack Housing: PBT + Glass Fiber (UL 94V-0 rated)\n\nContact Material: Phosphor Bronze with Nickel plating\n\nIDC Terminal: Phosphor Bronze with Tin plating (fits 22-26 AWG wire)\n\nMating Cycles: 750 cycles minimum (Jack) / 200 cycles minimum (IDC)\n\nOperating Temperature: -10°C to 60°C\n\nTransmission Standard: Compliant with ANSI/TIA/EIA 568C.2 and ISO/IEC 11801
