IP Camera Tester (IPC9310PLUS)

(24 reviews) In Stock

₵2,900.00 ₵2,498.93 13% OFF

Product Highlights

4K H.265 Decoding: Supports high-resolution mainstream video from 4K IP cameras for precise image evaluation. 5-in-1 Versatility: Provides testing for IP, TVI (8MP), CVI (8MP), AHD (5MP), and Analog (CVBS) camera formats. Intelligent IP Tools: Includes Rapid IP discovery, ONVIF one-click video viewing, and batch modification tools for Hikvision and Dahua cameras. Robust Power Support: Features a 48V standard PoE output (25.5W) and a DC 12V/3A output to power cameras directly from the tester. Integrated Cable Diagnostics: Equipped with a UTP Cable Tester to verify wire sequences and a PSE Voltage Test to check PoE power status. Network Management Suite: Comes with essential diagnostic tools including PING, IP Scan, and DHCP Server for full network health checks. Extended Field Use: The built-in 7.4V/3200mAh lithium battery provides 8 to 10 hours of continuous working time

Why Shop With Us

Fast Delivery

Delivery within 24-48 hours in Accra, 2-5 days nationwide

Secure Payment

100% secure payment options with SSL encryption

Easy Returns

7-day return policy for damaged or wrong items

24/7 Support

Dedicated customer support available anytime

Product Specifications

Type:IP Camera Tester

Compatibility:Universal

The IP Camera Tester (IPC9310PLUS) is a comprehensive, professional-grade diagnostic tool designed for the seamless installation and maintenance of modern security systems. It features a high-definition 4-inch IPS touch screen with an 800 x 480 resolution, providing clear visuals for both analog and IP camera feeds. Built on an Android platform, it offers a "Smart Managed" experience by allowing technicians to use specialized apps (like Hikvision SADP or Dahua Test Tool) for batch camera activation and network troubleshooting. Its portable, handheld design serves as a mobile workstation, replacing the need for a laptop, monitor, and multiple power supplies in the field.

Technical Specifications

The 4 inch Capacitive Touch Screen features an 800 x 480 IPS full view display providing a sharp and clear interface for mobile camera testing With a 10 100 1000Mbps Adaptive Ethernet Port and built in 2.4G WiFi it offers high speed connectivity and hotspot capability for network diagnostics Full IP Camera Support allows for 4K H.265 and H.264 mainstream display compatible with ONVIF and private protocols for Hikvision and Dahua The device provides Coaxial HD Support for TVI 8MP CVI 8MP and AHD 5MP resolution testing making it a versatile tool for hybrid surveillance systems Flexible Power Output options include 48V Standard PoE up to 25.5W and 12V 3A DC output to power cameras directly during installation Video Input is managed via a 1 channel BNC port and 1 channel HDMI port allowing for comprehensive signal verification across different hardware PTZ Control is highly compatible supporting over 30 industry protocols including Pelco D P Samsung and Panasonic for motorized camera testing Running on an Android OS with 8GB of internal storage it supports over 10 languages and provides an intuitive user experience for field technicians At a weight of approximately 0.45 kg this lightweight and portable tester is designed for comfortable one handed operation during long site visits
